ELROY
Wall Surface 4765-NPL.
Product Companion
ELROY
Wall Surface
Product Characteristics:
DESIGN:
Elegant and simple design, these fixtures are ADA compliant and are certified for wet location applications.
LIGHT SOURCE:
7W or 14W LED (4765-NPL) or 13W and 26W LED Chip-on-board (COB) emitter (4766-SIJ). Dimming available.
STRUCTURE:
Stamped steel structure with a highly reflective super-durable matte white powder coat finish and a silicone gasket for weatherproof installation (4765-NPL) or durable die cast aluminum enclosure, with black anodised finish, stainless steel spring clips (4766-SIJ).
DIFFUSER:
Translucent white rotomolded MDPE (4765-NPL) or compound lens structured around
layers of diffusing and conical deglaring prismatic sheet PMMA (4766-SIJ).
CERTIFIED:
CSA Listed to US and Canadian safety standards; 25°C ambient and wet-locations.
IP65 (4765-NPL) or IP64 (4766-SIJ) rated
Elegant and simple design, these fixtures are ADA compliant and are certified for wet location applications.
LIGHT SOURCE:
7W or 14W LED (4765-NPL) or 13W and 26W LED Chip-on-board (COB) emitter (4766-SIJ). Dimming available.
STRUCTURE:
Stamped steel structure with a highly reflective super-durable matte white powder coat finish and a silicone gasket for weatherproof installation (4765-NPL) or durable die cast aluminum enclosure, with black anodised finish, stainless steel spring clips (4766-SIJ).
DIFFUSER:
Translucent white rotomolded MDPE (4765-NPL) or compound lens structured around
layers of diffusing and conical deglaring prismatic sheet PMMA (4766-SIJ).
CERTIFIED:
CSA Listed to US and Canadian safety standards; 25°C ambient and wet-locations.
IP65 (4765-NPL) or IP64 (4766-SIJ) rated
Available Light Sources
LED.30.DP
14W, LED 3000K (Warm) PHASE DIMMING 120V
LED.30.DV
14W, LED 3000K (Warm) 0-10V DIMMING 120-277V
LED.30
7W, LED 3000K (Warm) 120-277V
LED.14.35.DP
14W, LED 3500K (Natural) PHASE DIMMING 120V
LED.35.DV
14W, LED 3500K (Natural) 0-10V DIMMING 120-277V
LED.35
7W, LED 3500K (Natural) 120-277V
LED.40.DP
14W, LED 4000K (Neutral) PHASE DIMMING 120V
LED.14.40.DV
14W, LED 4000K (Neutral) 0-10V DIMMING 120-277V
LED.40
7W, LED 4000K (Neutral) 120-277V
